MODEL

ZS110-13C

Engine Name

C110-B

Engine Type

Single cylinder, 4-stroke, air-cooling, SOHC, horizontally inclined by 10°

Displacement （ml)

106.7

Bore × Stroke （mm)

52.4×49.5

Compression Ratio

9.7：1

Max. Power （kW/rpm)

5.0/8000

Max. Torque （Nm/rpm)

6.9/6000

Max. Speed （km/h)

80

Fuel System

Carburetor/EFI

Ignition

CDI/ECU

Starting System

Electric/Kick

Brake

Front:Drum/Disc;Rear:Drum

Tire

Front:70/90-17,Rear:80/90-17

L×W×H （mm)

1900×680×1010

Wheelbase （mm)

1230

Seat Height （mm)

755

Min. Ground Clearance （mm)

120

Curb Weight （kg)

97

Fuel Tank Capacity （L)

4.5/4

Container Loading Quantity （40'HQ)

84
